With science and technology as the cornerstone, quality as life.Gabion Welcome You!
 |
| Place of Origin: | China |
| Brand Name: | XINGEBIN |
| Certification: | ISO9001 |
| Model Number: | R-yhw |
| Minimum Order Quantity: | 200 m2 |
|---|---|
| Price: | USD2.5-5.0/SQUARE METER |
| Packaging Details: | pallet |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 300M2/DAY |
| Material: | 45# Steel Wire | Wire Diameter: | 0.6mm-5mm |
|---|---|---|---|
| Application: | Woven Wire Mesh | Type: | Weave Wire Mesh |
| Wire Diameter: | 0.5-8mm | ||
| High Light: | Screen Wire Mesh 0.6mm,Woven Screen Wire Mesh,Crimped Woven Wire Mesh |
||
Woven Crimped Wire Mining Vibrating Screen Mesh with Hooked for Coal Mine Industry classification:
According to the different materials, it can also be called iron wire ginning net, galvanized ginning net, white steel ginning net, black steel ginning net, stainless steel ginning net 316L, 321), wire rod ginning net, copper clad steel ginning net.
Woven Crimped Wire Mining Vibrating Screen Mesh with Hooked depending on the application, the ginning nets can also be used as ore sieve ginning nets, pig ginning nets, barbecue ginning nets, granary ginning nets, and decorative ginning nets.
According to the form, it can also be called ginning net, embossed ginning net, ginning net.
Main use
Crimped wire mesh is widely used in mining, petroleum, chemical, sewage treatment, construction, machinery accessories, protective nets, grill nets, grill nets, handicraft nets, vibration screens, net baskets, food machinery nets, Cooker nets, wall nets, and grain can be used for the classification and screening of solid materials, the filtration of liquids and slurries, aquaculture, and civilian use.
Woven Crimped Wire Mining Vibrating Screen Mesh with Hooked for Coal Mine Industry material introduction:
| Material Grade | Chemical composition | Wire diameter | ||
| C | Si | Mn | mm | |
| 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | 2.00-6.00 |
| 50 | 0.47-0.55 | |||
| 55 | 0.52-0.60 | |||
| 60 | 0.57-0.65 | |||
| 65 | 0.62-0.70 | |||
| 72 | 0.67-0.75 | |||
| 65Mn | 0.62-0.70 | 0.90-1.20 | 2.00-14.0 | |
| Mesh opening | 0.75-100 | |||
| Width&Length | 1*2m, 2*2.5m,etc | |||
Woven Crimped Wire Mining Vibrating Screen Mesh with Hooked for Coal Mine
